Manganese Naphthenate (CAS 61790-10-1)
| CAS No. | 61790-10-1 |
|---|---|
| Alias | Manganese(II) naphthenate, Manganese soap |
| Category | Driers |
| Packaging | 180 kg |
Grade PID C-1 | Metal content 7±0.2%. Used as an auxiliary drier in oil-based paints, varnishes, and printing inks to enhance drying.
Introduction
Manganese naphthenate is a top drier, used to accelerate surface drying and shorten tack-free time in alkyd and epoxy ester systems. Like the cobalt naphthenates, it has the advantage of sitting outside the 2-EHA restriction that applies to the octoate family.
This grade is a 7 ± 0.2% manganese solution in 200# solvent oil, dark brown and viscous, with high metal-content tolerance for reproducible dosing.
Physical & Chemical Properties
Dark brown viscous liquid. Metal content 7 ± 0.2% Mn. Density 0.95–1.05 g/cm³ at 20 °C, viscosity ≤200 mPa·s at 25 °C, flash point ≥40 °C closed cup, acid value ≤10 mg KOH/g, moisture ≤0.5%.
Applications
Top drier in combination with cobalt or zirconium, reducing tack-free time in alkyd systems. Good solubility in common paint solvents. Cost-effective within traditional drier systems.
Regulatory status
This is the same substance as the market knows well, and it is a manganese drier rather than a cobalt one, so it is outside the cobalt conversation entirely.
Where it differs from our manganese octoate is the acid. Manganese octoate is built on 2-ethylhexanoic acid, which carries a harmonised Repr. 1B classification under CLP entry 607-230-00-6 and was brought into Annex XVII Appendix 6 by Commission Regulation (EU) 2023/1132 from 1 December 2023. Manganese naphthenate is built on naphthenic acid and is not caught by that listing. If a customer is moving away from octoate driers, this is one of the grades that gets them there.
Manganese naphthenate has no harmonised CLP classification, is not on the REACH Candidate List, and is not subject to an Authorisation List entry. Transport class UN 1268, Class 3, PG III, from the mineral spirits carrier.
Handling & Storage
Flammable liquid. Store cool, dry and well ventilated away from ignition sources. Consult the SDS.
Packaging
25 kg and 200 kg drums. Shelf life 12 months sealed. COA and SDS supplied.
